SPF (Super Pinion Flange) Replacement Heavy Duty Pinion Flange Kits for all Long Nose Differentials
The 'Super Pinion Flange' is a completely unique solution to the age old problem of Land Rovers various (dreadful) Pinion Seals and Shields.
PLEASE DO NOT BUY If you're unable to potentially 'fettle' them to fit. Due to minor variations in LR Casings they may NOT always be a 100%
straightforward fit.
Click for Video explaining fitting process and potentially what might needed
in 'tweaking' them to fit. er ie LR tolerances are 'not quite as good' as a 5 Axis CNC Machining Center. !
Kit 1 - 'Castle Nut' Kit
Pinions with a Castle Nut + Split Pin is this Kit. It will also fit the 4 Spline older Flanges and the later
24 Spline.
Kit comprises of a SPF Aliuminum Flange, New Corteco Pinion Seal, new 'Castle Nut' and Split Pin.
Kit 2 - 'Central Bolt' Kit.
Pinions with a 'Bolt' screwed into the end means you have Kit 2. Pinions may be Round or Square - fits either.
Kit comprises of a Xcess4x4 SPF Aliuminum Flange, New Corteco Pinion Seal, and a new 'Pinion Bolt'
Kit 3. - 'Nyloc' Kit.
On Differentials with a 'Nyloc' nut on the end of the Pinion, including Discovery 2 '3 Bolt Flanges' this Kit.
Kit comprises of a Xcess4x4 SPF Aliuminum Flange, New Corteco Pinion Seal + new 'Nyloc'.
Kit 4. - TWO of any of the above Kits - 'Mix n Match' !
If you would like to buy a Pair of SPFs then Kit 4 is the one to buy.
You can have 2 x of whichever Kit(s) you need - just advise on payment
as to which ones you would like - and yes, you can have different ones,
as sometimes the front and rear Differentials may need different kits. With Kit 4 buying 2 also gives you a small discount.
Kit 5. - A Full Super Flange Kit (has all 3 Pinion end types) + NEW 'Round Type" Late Pinion Flange - Pressed on ready to fit !
Here you get as in the Picture - A New 'Late Type' Pinion Round Type Drive Flange, with one of our Superflanges already pressed on ready to fit,
and the new seal, and ALL 3 x Pinion end fittings
Kit 6. - A Pair - i.e. 2 x Full Kit 5s as above.
That's 2 x New Round 'Late Type' Drive Flanges, both with new seals, all 3 x pinion end fittings, and 2 x of the SPF pressed on all ready to fit.
Kit 7. - A New SQUARE 4 Spline Drive flange (Early LR Differentials) + new SPF Fitted Inc Seal etc
On Earlier Land Rover Differentials, the pinion has a 'Coarse' 4 Spline vs the later 24 Spline version. This Kit is for 1 x Square coarse 4 spline Drive Flange with a SPF Fitted, and comes with new seal etc.
Kit 8. - A Pair of New SQUARE 4 Spline Drive flange (Early LR Differentials) + new SPF Fitted Inc Seal etc
That's 2 of 'Kit 7' - ie 2 x Square coarse Drive Flanges, both with new seals, and 2 x of the SPF pressed on all ready to fit.
